KEM Density/Specific Gravity Meters

kem-logo-250px_A
Contact us for Selection Help?

Density/Specific Gravity Meter
DA-860/850/840

The convenient, efficient and reliable DA-800 series is KEM’s (Kyoto Electronics Manufacturing Co., Ltd.) 6th generation line of density/specific gravity meters, inheriting technology developed with market needs firmly in mind.

The DA-800 series density meters measure the density/specific gravity of liquid samples by employing an oscillating sensor to determine resonant frequency. What’s more, the instruments can calculate sample concentration according to common industry standard formulas and tables.

The instruments have a built-in temperature stabilizing function, allowing you to measure density/specific gravity at your desired temperature.

Measurement can be conducted with as little as 1mL of sample (if injected manually), and in as fast as 10 seconds for a temperature-stabilized sample (when viscosity correction is disabled). All models in the DA-800 range come with viscosity correction functionality as standard.

Data Integrity (DI) support functions are provided as standard to help you maintain and manage your valuable data.

The interface has been enhanced to support a variety of uses, such as a separate structure for the operation unit (tablet/PC) and measurement unit, wireless LAN connection, and connection of multiple units.

The instrument has a space-saving design and can be integrated with a semiautomatic cleaning unit (optional). Also included is a camera for viewing inside the measurement cell, improving reliability, convenience, and efficiency.

  • Separate operation unit and measurement unit
  • Semiautomatic cleaning unit
  • High reliability
  • Equipped with a camera for viewing the measurement cell
  • Short measurement time
  • Multiple management by a single operation unit
Features
DA-800 series
da6xx-density-meter

Density / Specific Gravity Meter
DA-650/645/640

  • Equipped with sampling and dry pump
  • Measuring Range:±0 – 3 g/cm3
  • Temp Range:±0 – 96℃ (32 – 204.8°F)
  • Hassle-free and safe measurement
  • Easy check of measurement cell
  • No air bubbles, no contamination
  • Calibration at one temperature
  • Easy data transfer
  • Connection to barometer (Option / NON-CE)
Features

Density / Specific Gravity Meter
DA-100

  • With thermal control built-in
  • Reproducibility: ±1 X 10-3g/cm3
  • Temperature: 15 – 40°C

The built-in thermostatic control makes measurement stable in resulting values.
Thus, human error is eliminated in addition to easy operation and high precision.

  • Measurement in a short period of time
  • With built-in thermal control
  • High precision thermal sensor is installed in measuring cell
  • Concentration can be obtained by conversion.
Features
da100
da130n

Portable Density/Specific Gravity Meter
DA-130N

  • Portable type for hand carry
  • With temperature compensation automatically
  • Sampling is single hand controlled
  • Precision: ±1 x 10-3g/cm3
  • Temperature: 0 – 40°C
  • Sampling volume and speed is single hand controlled. (Patent pending)
  • Operative either by right or left hand, the cell can be viewed during measurement.
  • Light weight allows operators to feel tireless in the normal operations.
  • Viscous liquid up to ca 2000 mPa･s can be sampled in.
  • The display shows density, temperature compensated density, specific gravity, temperature compensated specific gravity, Brix %, alcohol concentration, sulfuric acid concentration, API degree, Baume degree, Plato and Proof degree and the like.
  • Graphic LCD can display temperature, sample number, auto sensing oscillation stability, auto data saving, auto data output, data deletion, buttery capacity indicator, and the like.
  • Life of battery is increased two times more than conventional makes, providing much longer operation time.
Features
